What!? No tally!?
FlexTally Pro can fix that right away.
Compatible with over 100 switcher models
Supports GPIO (contact signal), USB, or Ethernet to interface with tally output of your switcher.
- USB
- GPIO
- Ethernet
Supports Up to 128 Lamps
Supports up to 128 tally inputs with Ethernet interfaced switchers, or up to 16 with GPIO (contact signal) and USB. Tally inputs can be freely mapped to control up to 128 lamps. Can be used on a wide range of scales, from portables to studio grade switchers with many inputs.
Mixed Wired and Wireless Connections
433MHz Wireless Connection
Enhanced Expression With Matrix LEDs
Each FlexTally Pro Lamp Unit is equipped with 60 high-brightness full-color LEDs capable of displaying preset numbers, custom patterns or solid red and green indicators.
The lamp’s brightness can be adjusted in four levels, ensuring optimal visibility in environments ranging from dark indoor studios to bright outdoor locations.
Flexible Power Options
Compact Body
Diverse Expressions
Advanced Tally Lamp
Highly Reliable and
Robust Base Unit with
Flexible Interfaces
The FlexTally Pro Base Unit is a control hub with multiple connection options in a compact 1/3 rack-width design and ready to use right away. Features include:
- Redundant power support: Two USB Type-C inputs for reliability.
- Self standing operation: Configure and control directly via onboard buttons.
Advanced Customization via Embedded App
Use the embedded FlexTally Pro App to:
- Assign specific tally inputs to each lamp.
- Customize matrix LED displays for your specific needs. Whether you’re working in a small studio or a large-scale production, FlexTally Pro adapts to any scenario.
Evolved Tally, Superior Performance
| FlexTally Pro | Company A tally product | Company B tally product | |
|---|---|---|---|
| Compatible switchers | Click here for the latest list | 38 models from 7 companies | N/A |
| Max # of lamps can be connected | 128 | 16 | 16 |
| Lamp Connection Method | Wireless (433MHz band) and wired (Ethernet) can be mixed | Wireless (2.4GHz band) | Wireless (433MHz) wired (RS-485) |
| Lamp Power Supply | PoE USB Type-C external battery (LP-E6 shape compatible) | USB Type-C，external battery (dedicated product) | USB Type-C，external battery (dedicated product) |
| Lamp Lighting Color | Full color | 2 colors (red，green) | 2 colors (red，green) |
| Lamp Fixing Method | 1/4-20 UNC nut | Clip | 1/4-20 UNC nut |
FAQ
Q1. Which switchers are compatible with FlexTally Pro?
A1. FlexTally Pro supports most major switchers on the market. It connects via GPIO, Ethernet, or USB, offering compatibility across diverse systems.
Q2. How does the wireless connection compare to the previous FlexTally?
A2. The previous model, FlexTally, equips the transmitter antenna on the Station Unit, limiting its ability to extend the wireless range. FlexTally Pro overcomes this limitation by allowing multiple lamps to function as antennas, expanding the wireless range and ensuring stable operation.
Q3. Can I connect the lamps via a wired connection?
A3. Yes, standard LAN cables can be used for wired connections. You can also mix wired and wireless lamps for added flexibility.
Q4. What are the power options for the lamp units?
A4. The lamps support PoE, USB Type-C, and LP-E6 compatible external batteries, allowing you to choose the best power source for your setup.
Q5. Can the lamps display colors beyond red and green?
A5. Yes, the matrix LEDs support full-color displays, including custom patterns, in addition to red/green for program/preview. You can also adjust brightness and lighting effects based on your needs.
